Answer to Question #197210 in Mechanical Engineering for Ash

Question #197210
Define the terms: (i) Plane Stress (iii) Mohr's Circle and (iii) Fatigue failure.



and



How do you find yield strength of a material if distinct yield point is not found in the

material stress strain graph? Explain with necessary sketches.
1
Expert's answer
2021-05-31T06:40:36-0400

Plane stress is defined as a stress condition in which the normal stress, 0, and shear stresses, Orz and Oy z, oriented perpendicular to the x-y plane, are considered to be zero. The body's geometry is roughly that of a plate, with one dimension significantly smaller than the others.


The Mohr circle is used to calculate the stress components and, that is, the coordinates of any point on the circle acting on any other plane passing through and forming an angle with the plane. Two ways may be employed for this: the double angle and the Pole or origin of planes.


The beginning and spread of fractures in a material caused by cyclic stress is referred to as fatigue failure. Once a fatigue crack has formed, it increases a little amount with each loading cycle, resulting in striations on some portions of the fracture.


The FoS is calculated by dividing the yield strength by the cable's effective maximum applied stress. When testing metals, the computation of yield is especially significant.
